Design & Drawings


Architectural Drawings

  • 2D floor plans.

  • 2D furniture layout.

  • 2D Working drawings.

  • Doors and window schedule.

  • 3D rendered view.

  • 2D elevation working drawings.


Note:

This Floor plan is just for reference only, Floor plan for each project will be designed as per client’s requirements.


Floor plan

Note:

This elevation image is just for reference only, Elevation for each project will be designed as per client’s taste and requirement.



Structural Design and Drawings :

  • Structural design shall be based on soil investigation report.

  • Center line marking drawings

  • Excavation drawings.

  • Footings and Columns drawings

  • Plinth beam drawings

  • Roof slab shuttering drawings

  • Roof slab reinforcement drawings

  • Roof slab and Beam drawings for each level

  • Staircase drawings

  •
